Jiangsu Fast Machinery Co., Ltd.
PRODUCTS

STZB Retainer with jacket

Device Description

  • The preferred curing equipment for shrimp pellet mill and high grade pig pelletizer.
  • The volume of retentioner is increased and the steam jacket is heated
  • The contact part with the material is stainless steel.
  • Special spiral feed structure ensures first in first out, reduces residual and cross contamination.
  • Product temperature can reach95c°-100c° and tempering time is 2 - 4 minutes. The particles tempered by retainer have the characteristics of high maturity, neat incision and good granulation performance.

Technical Parameters



Modle

Effective Volume

(L)

Diameter*length

mm

Powder

kw

Capacity (t/h)

STZB1000

1000

600*3000

5.5

3-12

STZB1500

1500

800*3200

7.5

4-20

STZB2000

2000

1000*3200

11

5-30
